Rotation Luminaire Goniophotometer

LSG-1700 goniophotometer is an automatic goniophotometric instrument for luminous intensity distribution measurement with facility for rotating the light source. It is for industrial laboratory photometric data measurement of luminaires such as LED luminaires, HID luminaires, fluorescent lamps and so on.

Rotation Luminaire Goniophotometer

Standard:
LM-79-19 “Optical and Electrical Measurements of Solid State Lighting Products”
EN13032-1 “Light and lighting – Measurement and presentation of photometric data of lamps and luminaires – Part 1: Measurement and file format; German version EN 13032-1:2004+A1:2012”
IES LM-80-08 “Measuring Lumen Maintenance of LED Light Sources”
CIE-121 “The Photometry and Goniophotometry of Luminaires”
CIE-70  “The Measurement of Absolute Luminous Intensity Distribution”
IES LM-75  “GoniophotometerTypes and Photometric Coordinates”

IES file testing Goniophotometer Specification:

• Meets the requirements of CIE-70, IEC, IES LM-79, LM-80, EN13032-1 & GB standards
• Reaching many measurement ways C-Gamma
• The luminaries under test rotates around an angle of (γ)±180°(or 0-360°) and the luminaries rotates around itself with an angle of (C)±180°(or 0-360°)
• Luminosity testing range: Illuminance 0.001lx~10,000lx; Light Intensity 1.0cd～10^7cd (detector)
• The accuracy of angle: 0.2°
• Photometry accuracy: CIE Class 1
• Testing accuracy: 3%(Under Standard lamp); Stray Light: less than 0.2%
• English version software can run on Win7, Win8 or Win10, Win11

LISUN LSG-1700 Rotation Luminaire Goniophotometer – After-sales Frequently Asked Questions (FAQ)
LISUN LSG-1700 Rotation Luminaire Goniophotometer were in the market for more than 10 years, LISUN engineers service team already summary the most of the After Sales Questions and Answers in the above link. Please read it carefuly, you can solve the most of the problems by yourself if you have some questions while using the instruments. LISUN will be continue to update this pages and more FAQ can be found in this topic link.
